Fence post, drilled, angled, for mesh wire structures
Art.-No. 619862
- Length:
- 2750 mm
- Angulation at least:
- 350 mm
- Post dia.:
- 76 mm
- Wall thickness:
- 2
- No. of wire holders:
- 5
- :
- 15 years
- Material/surface:
- raw steel, hot-dip galvanised passivated, for setting in concrete
- Weight per UQ (kg):
- 10.848 kg
- Distortion:
- 45 °
- Contents Unit:
- 1 Piece
Article-No.
Length
Angulation at least
Post dia.
Wall thickness
Action
Article-No.
615765
Length
1500 mm
Angulation at least
350 mm
Post dia.
48 mm
Wall thickness
1.5
Article-No.
615918
Length
1750 mm
Angulation at least
350 mm
Post dia.
48 mm
Wall thickness
1.5
Article-No.
616069
Length
2000 mm
Angulation at least
350 mm
Post dia.
48 mm
Wall thickness
1.5
Article-No.
616212
Length
2250 mm
Angulation at least
350 mm
Post dia.
48 mm
Wall thickness
1.5
Article-No.
616366
Length
2500 mm
Angulation at least
350 mm
Post dia.
48 mm
Wall thickness
1.5
Article-No.
616441
Length
2750 mm
Angulation at least
350 mm
Post dia.
48 mm
Wall thickness
1.5
Article-No.
616519
Length
3000 mm
Angulation at least
350 mm
Post dia.
48 mm
Wall thickness
1.5
Article-No.
616663
Length
3250 mm
Angulation at least
350 mm
Post dia.
48 mm
Wall thickness
1.5
Article-No.
617769
Length
1500 mm
Angulation at least
350 mm
Post dia.
60 mm
Wall thickness
1.75
Article-No.
617912
Length
1750 mm
Angulation at least
350 mm
Post dia.
60 mm
Wall thickness
1.75
Article-No.
618063
Length
2000 mm
Angulation at least
350 mm
Post dia.
60 mm
Wall thickness
1.75
Article-No.
618216
Length
2250 mm
Angulation at least
350 mm
Post dia.
60 mm
Wall thickness
1.75
Article-No.
618360
Length
2500 mm
Angulation at least
350 mm
Post dia.
60 mm
Wall thickness
1.75
Article-No.
618445
Length
2750 mm
Angulation at least
350 mm
Post dia.
60 mm
Wall thickness
1.75
Article-No.
618513
Length
3000 mm
Angulation at least
350 mm
Post dia.
60 mm
Wall thickness
1.75
Article-No.
618667
Length
3250 mm
Angulation at least
350 mm
Post dia.
60 mm
Wall thickness
1.75
Article-No.
619862
Length
2750 mm
Angulation at least
350 mm
Post dia.
76 mm
Wall thickness
2
Article-No.
620011
Length
3000 mm
Angulation at least
350 mm
Post dia.
76 mm
Wall thickness
2
Article-No.
620165
Length
3250 mm
Angulation at least
350 mm
Post dia.
76 mm
Wall thickness
2
- with drill holes for wire holders
- Unattached green or grey wire holders and a plastic cap included.
- Additional bores and tension wire holders.
- Additional barbed wire holders on the angle.
- Delivery in special lengths
