• Barrel bolt with knob handle, without spring, with countersunk screw holes, Material: raw steel, Surface: galvanised, thick-film passivated, with attached staple, Plate length: 47 mm, Plate width: 46 mm, Bolt-Ø: 9 mm, Loop width: 13 mm, Loop length: 52 mm, Total length: 80 mm, No. of holes: 6, Hole: Ø4.2 mm
  • Barrel bolt with knob handle, without spring, with countersunk screw holes, Material: raw steel, Surface: galvanised, thick-film passivated, with attached staple, Plate length: 47 mm, Plate width: 46 mm, Bolt-Ø: 9 mm, Loop width: 13 mm, Loop length: 52 mm, Total length: 80 mm, No. of holes: 6, Hole: Ø4.2 mm

Barrel bolt with knob handle

with countersunk screw holes
Art.-No. 123376
3 Variants
Dimension a:
47 mm
Dimension b:
46 mm
Dimension c-Ø:
9 mm
Dimension d:
13 mm
Dimension e:
52 mm
Dimension f:
80 mm
Extension length:
27 mm
Quantity x hole Ø:
6 x Ø4.2 mm
Material/surface:
raw steel, galvanised, thick-film passivated, with attached staple
Systems:
Bolts
Surface / Colour:
VERZ
Material:
Steel
Panel width:
46 mm
:
80 mm
Panel length:
47 mm
:
9 mm
Weight per UQ (kg):
0.082 kg
Contents Unit:
12 Piece
Article-No.
Dimension a
Dimension b
Dimension c-Ø
Dimension d
Action
Article-No. 123352
Dimension a 33 mm
Dimension b 35 mm
Dimension c-Ø 7 mm
Dimension d 10 mm
Article-No. 123369
Dimension a 39 mm
Dimension b 38 mm
Dimension c-Ø 8 mm
Dimension d 10 mm
Article-No. 123376
Dimension a 47 mm
Dimension b 46 mm
Dimension c-Ø 9 mm
Dimension d 13 mm
  • with reinforced screw holes
  • When closed, the locked head prevents undesirable loosening due to vibration.
