• Hook on plate, DI, with countersunk screw holes, Material: raw steel, Surface: galvanised, thick-film passivated, Size back set-Ø: 13 mm, Distance pin - plate: 11 mm, Plate height: 100 mm, Plate width: 35 mm, Length of pin: 40 mm, Material thickness: 4.00 mm, No. of holes: 4, Hole: Ø6.5 mm
  • Hook on plate, DI, with countersunk screw holes, Material: raw steel, Surface: galvanised, thick-film passivated, Size back set-Ø: 13 mm, Distance pin - plate: 11 mm, Plate height: 100 mm, Plate width: 35 mm, Length of pin: 40 mm, Material thickness: 4.00 mm, No. of holes: 4, Hole: Ø6.5 mm

Hook on plate, DI

with countersunk screw holes
Art.-No. 311230
4 Variants
Dimension a-Ø:
13 mm
Dimension b:
11 mm
Dimension c:
100 mm
Dimension d:
35 mm
Dimension e:
40 mm
Fastening type:
for screwing on
Material thickness:
4 mm
Quantity x hole Ø:
4 x Ø6.5 mm
Material/surface:
raw steel, galvanised, thick-film passivated
Systems:
Band hooks and hooks
Surface / Colour:
VERZ
Material:
Steel
Backset-Ø:
13 mm
Panel width:
35 mm
Weight per UQ (kg):
0.209 kg
Contents Unit:
10 Piece
  • Suitable fasteners can be found in the range “Screws and accessories”.
