• Toothed wood connector, Material: raw steel, Surface: sendzimir galvanised, with marking in accordance with EN 14545, External dia.: 62 mm, Inner dia.: 21 mm, Designed for standard cross-sections made from solid structural timber (SST) and glued laminated timber (glulam), CutCase
  • Toothed wood connector, Material: raw steel, Surface: sendzimir galvanised, with marking in accordance with EN 14545, External dia.: 62 mm, Inner dia.: 21 mm, Designed for standard cross-sections made from solid structural timber (SST) and glued laminated timber (glulam), CutCase

Toothed wood connector

Art.-No. 334444

raw steel, sendzimir galvanised, with marking in accordance with EN 14545

3 Variants
Dimension a-Ø:
62 mm
Dimension b-Ø:
21 mm
Fastening type:
for screwing on
Material/surface:
raw steel, sendzimir galvanised, with marking in accordance with EN 14545
Surface / Colour:
VERZ
Material:
Steel
:
62 mm
:
21 mm
Approval:
EN14545:2008
Weight per UQ (kg):
0.030 kg
For screw:
M20
Contents Unit:
50 Piece
Article-No.
Dimension a-Ø
Dimension b-Ø
Fastening type
Material/surface
Action
Article-No. 334437
Dimension a-Ø 50 mm
Dimension b-Ø 17 mm
Fastening type for screwing on
Material/surface raw steel, sendzimir galvanised, with marking in accordance with EN 14545
Article-No. 334444
Dimension a-Ø 62 mm
Dimension b-Ø 21 mm
Fastening type for screwing on
Material/surface raw steel, sendzimir galvanised, with marking in accordance with EN 14545
Article-No. 338039
Dimension a-Ø 75 mm
Dimension b-Ø 26 mm
Fastening type for screwing on
Material/surface raw steel, sendzimir galvanised, with marking in accordance with EN 14545
  • type C1, double-sided with teeth
  • produced in accordance with EN912 (DIN 1052)
