Window grille Basic II in customised dimensions
for mounting in the window reveal or on the outside wall
Art.-No. 564421
- reveal width:
- 946 - 1320 mm
- reveal height:
- 1401 - 2000 mm
- Frame width:
- 1026 - 1400 mm
- Frame height:
- 1401 - 2000 mm
- Frame thickness:
- 30 x 20 mm
- Note on filler material:
- Round bar
- Filler material Ø:
- 12 mm
- Traverse:
- with
- Number of attachment points:
- 8
- :
- 15 years
- Material/surface:
- raw steel, hot-dip galvanised passivated, mounting on the wall
- Systems:
- Basic II
- Surface / Colour:
- FVZ
- Weight per UQ (kg):
- 32.984 kg
- Contents Unit:
- 1 Piece
Article-No.
reveal width
reveal height
Frame width
Frame height
Action
Article-No.
564322
reveal width
320 - 570 mm
reveal height
400 - 800 mm
Frame width
400 - 650 mm
Frame height
400 - 800 mm
Article-No.
564339
reveal width
571 - 945 mm
reveal height
400 - 800 mm
Frame width
651 - 1025 mm
Frame height
400 - 800 mm
Article-No.
564346
reveal width
946 - 1320 mm
reveal height
400 - 800 mm
Frame width
1026 - 1400 mm
Frame height
400 - 800 mm
Article-No.
564353
reveal width
1321 - 1820 mm
reveal height
400 - 800 mm
Frame width
1401 - 1900 mm
Frame height
400 - 800 mm
Article-No.
564360
reveal width
320 - 570 mm
reveal height
801 - 1400 mm
Frame width
400 - 650 mm
Frame height
801 - 1400 mm
Article-No.
564377
reveal width
571 - 945 mm
reveal height
801 - 1400 mm
Frame width
651 - 1025 mm
Frame height
801 - 1400 mm
Article-No.
564384
reveal width
946 - 1320 mm
reveal height
801 - 1400 mm
Frame width
1026 - 1400 mm
Frame height
801 - 1400 mm
Article-No.
564391
reveal width
1321 - 1820 mm
reveal height
801 - 1400 mm
Frame width
1401 - 1900 mm
Frame height
801 - 1400 mm
Article-No.
564407
reveal width
320 - 570 mm
reveal height
1401 - 2000 mm
Frame width
400 - 650 mm
Frame height
1401 - 2000 mm
Article-No.
564414
reveal width
571 - 945 mm
reveal height
1401 - 2000 mm
Frame width
651 - 1025 mm
Frame height
1401 - 2000 mm
Article-No.
564421
reveal width
946 - 1320 mm
reveal height
1401 - 2000 mm
Frame width
1026 - 1400 mm
Frame height
1401 - 2000 mm
Article-No.
564438
reveal width
1321 - 1820 mm
reveal height
1401 - 2000 mm
Frame width
1401 - 1900 mm
Frame height
1401 - 2000 mm
- Window grille customised production on request
- please indicate the reveal width and the reveal height as dimensions
- When mounting the window grille to the wall, the window grille must be wide enough so that the fixing drill holes are at least 80 mm from the window reveal. Otherwise the masonry may break.
- Please order the fastening and screw sets separately.
